JYBV-08
OEM
Size: 1/4'',3/8'',1/2'',3/4'',1'',11/4'',11/2'',2'',21/2'',3'',4''
Meterial: Forged Brass (CW617N,CW614,CW602N,ASTM C 37700)
Technical Specification:
Norminal pressure: 3.0Mpa
Tested Pressure: 2.0Mpa
Working medium: Water, oil, gas
Working temperature: -20° C≤ T≤ 120° C
Thread standard: According ISO228, ISO7/1, DIN2999/
For the handle, it could be changed to Zinc alloy and aluminum handle
Package details: Each valve by one polybag, inner box, Cartons with wooden pallets
Application: House connection and drinking meter networks, water pipe connection and flow control
brass forged body, brass ball chrome plated,, brass stem and brass handle. For water meter before or after water meter PTFE packing with free nut and DECA fittings.Brass lockable ball valve for water meter with female thread, with brass body, anti-theft short or long handle
Material | Forged Brass ( CW617N, CW614 ,CW602N,ASTM C37700) |
Surface | Natural brass/ chrome plated |
Size | 1/4" to 4" |
Testing pressure | 100% tested with 0.6MPa - 0.8MPa by air |
Connection | Female thread x Female thread ,FXM,MXM |
Valve guarantee | 3 Years |
Samples time | 3 days - Current type |
OEM Acceptable | Yes /ODM , |
Size: 1/4'',3/8'',1/2'',3/4'',1'',11/4'',11/2'',2'',21/2'',3'',4''
Meterial: Forged Brass (CW617N,CW614,CW602N,ASTM C 37700)
Technical Specification:
Norminal pressure: 3.0Mpa
Tested Pressure: 2.0Mpa
Working medium: Water, oil, gas
Working temperature: -20° C≤ T≤ 120° C
Thread standard: According ISO228, ISO7/1, DIN2999/
For the handle, it could be changed to Zinc alloy and aluminum handle
Package details: Each valve by one polybag, inner box, Cartons with wooden pallets
Application: House connection and drinking meter networks, water pipe connection and flow control
brass forged body, brass ball chrome plated,, brass stem and brass handle. For water meter before or after water meter PTFE packing with free nut and DECA fittings.Brass lockable ball valve for water meter with female thread, with brass body, anti-theft short or long handle
Material | Forged Brass ( CW617N, CW614 ,CW602N,ASTM C37700) |
Surface | Natural brass/ chrome plated |
Size | 1/4" to 4" |
Testing pressure | 100% tested with 0.6MPa - 0.8MPa by air |
Connection | Female thread x Female thread ,FXM,MXM |
Valve guarantee | 3 Years |
Samples time | 3 days - Current type |
OEM Acceptable | Yes /ODM , |
